THINKTTE 780 – Professional Gearbox Flushing Device

The THINKCAR TTE 780 is a powerful and fully automatic solution for changing transmission fluid and cleaning automatic transmissions. Using state-of-the-art technology, it enables precise and efficient flushing, replacing nearly 99% of the old fluid —for improved shifting performance and a longer transmission life.

Main features & benefits

✅ Fully automatic transmission flushing – precise and safe exchange of old and new oil.
✅ Integrated vehicle database – Contains standard oil quantities for different vehicle models to ensure accurate filling.
✅ Intelligent oil flow detection – Automatic identification of the gearbox oil flow direction for easy handling during flushing.
✅ Oil change & cleaning – Before the transmission flush, the device can clean the automatic transmission to remove deposits.
✅ Temperature monitoring – Displays the old and new oil temperature for safe and precise maintenance.
✅ Electronic control – High-precision exchange through intelligent, electronic control.
✅ Oil refill function – The user can adjust the oil level of the gearbox if necessary.
✅ Oil preheating function – Heats the oil specifically to prevent the thermostat from closing during flushing (optional).
✅ Pressure monitoring & data logging – Visualized display of hydraulic pressure and integrated pressure sensors for safe use.
✅ Pressureless oil draining – Automatic reduction of the amount of oil in the gearbox in preparation for the change.
✅ Built-in printer – Print maintenance reports for easy documentation.
✅ Large 7-inch touchscreen – User-friendly and intuitive control panel.

Technical data

• Operating temperature: -10 to 40°C

• Oil exchange precision: ±0.01L

• Voltage: DC 12V

• Maximum power: 150W

• Oil tank capacity: 2 x 20L

• Noise level: <70db

• Oil filter accuracy: 5μm

• Pressure range: 0–150 psi

• Hose lengths:

  • Oil and return line: 2.5m

  • Oil drain line: 1.5m

• Touchscreen size: 7 inches

• Weight: 50 kg

The THINKCAR TTE 780 is the ideal solution for workshops and professional users who want to perform reliable, automatic transmission flushing. With its intelligent control system, comprehensive vehicle database, and precise oil change technology, it ensures maximum efficiency and safety in the maintenance of automatic transmissions.
